OS417MD POF Sender ST/SC/FC



The sender is optimized for POF (Plastic Optical Fiber) and larger core multimode applications. The sender has a 650 nm universal connector and a 850 nm ST, SC, FC connector. The light source is designed for performing insertion loss measurements on fiber optic links when used with an optical power meter. Whether testing outside plant or premise an optical source is the perfect tool when combined with an optical power meter. The output is stabilized to ensure accurate test results per current TIA/EIA requirements. The wavelengths are individually adjustable with a mechanical screw to have a variable attenuator or to reduce the output power. This make it able to save battery power when high optical output power is not necessary, or to turn up the power to test long runs. This unit is easy to operate with only a wavelength/power switch, which selects optical wavelengths or disables the unit. The sender is delivered in a protective rubber boot.


Features

OS417MD Features:
lAdjustable power output with mechanical screw
lCertify links per TIA/EIA standards
lLow battery indicator
lRugged
lHandheld
lLightweight
lEasy to use

OS417MD Package Contents:
1OS417MD POF Sender ST/SC/FC
1Product Spec Sheet
1Carrying Pouch
1CALS Calibration Sender
1Trim Tool

OS417MD Options:
  - See options list

Specifications

OS417MD (POF APPLICATIONS)SPECIFICATIONS, KEY FEATURES AND APPLICATIONS
ApplicationsPlastic, large core and multimode
Wavelength (λ)650nm and 850nm
Output typeLED
Modulated Frequencies

CW (Continuous Wave)

Stability, 1 hourLess than 0.5 dB
Power Output>-17dBm at 850nm, individually adjustable with mechanical screw
ConnectorsUniversal for 665 nm and ST for 850 nm
Controls

Front panel slide switches

Power2 AA Batteries or AC Power Converter
Low battery indicator

Yes

Protective rubber bootYes
Enclosure SizeL: 125 mm, W: 70 mm, H: 30 mm
Weight180 gram
Operation Temperature-10°C to +50°C (45% Hum, non condensing)
Storage Temperature-20°C to +60°C (75% Hum, non condensing)

Qualified

CE, RoHS and WEEE
